24V desktop supply with a two-pole output lead
Match the output rating and connector to the lighting assembly when ordering FY2400800. Its label specifies a 24V DC, 0.8A output and an AC100–240V, 50/60Hz input. The corresponding photograph shows a black enclosed supply with a mains inlet and a fixed lead ending in a moulded two-pole connector.
For display manufacturers, lightbox fabricators and lighting distributors, send the load specification and mating-connector drawing with the enquiry. Include the mains-cord requirement, cable lengths, destination and target quantity to define the sample and bulk-order configuration.
FY2400800 label and connection specification
| Specification | FY2400800 |
|---|
| Model on the matching label | FY2400800 |
| Output line on label | 24V DC, 0.8A |
| Calculated nominal output power | 19.2W (24V × 0.8A) |
| Input line on label | AC100–240V, 50/60Hz |
| Location instruction on label | Dry location use only |
| Matching case photograph | Black enclosed desktop format with mains inlet |
| Matching output connection | Fixed lead with moulded two-pole connector |
| Order configuration | Mains cord, mating connector, polarity and cable lengths to confirm |
Match the output connector and lighting load
Provide the lighting input specification, complete connected load and mating-connector drawing. Identify the contact dimensions, polarity and required cable length so the connection can be confirmed for the ordered version.
The 0.8A label rating applies to the supply as a whole. The listed 19.2W is the nominal calculation from 24V × 0.8A. Agree the complete supply configuration and installation requirements with the sample.
Mains cord photographs and model distinction
The four additional photographs below are labelled FY1202000, with a 12V DC, 2A OUTPUT line. They show AU, US, EU and UK mains-cord appearances respectively. Their electrical ratings belong to FY1202000.
Use these photographs to communicate the required cord appearance. Confirm the exact mains cord, inlet, output connector and supplied scope on the FY2400800 sample and quotation. The 24V specification table above refers to the matching FY2400800 label.
Desktop lighting supply samples and bulk orders
Wholesale orders start at 20 pcs, with lower unit prices at higher quantities. Samples are available for load and connector evaluation. Sample charges and shipping are confirmed separately. Standard lead time is 12–18 days.
OEM, ODM and private-label enquiries can include electrical requirements, cable and connector drawings, product marking and packing. Send the target quantity and destination to confirm the custom scope, pricing and documentation. Custom schedules and transit time are agreed separately.
24V power supply purchasing questions
What output is stated on the FY2400800 label?
The dedicated OUTPUT line states 24V DC and 0.8A. The nominal calculation is 19.2W from 24V × 0.8A.
Why do the mains-cord photographs show 12V 2A labels?
Those four photographs are labelled FY1202000 and show cord appearances on a different supply model. Their 12V 2A ratings do not describe FY2400800. Approve the exact FY2400800 cord and connection with the sample.
Is the pictured output a DC barrel plug?
The matching FY2400800 photograph shows a moulded two-pole connector. Send the mating-connector drawing and polarity requirement to confirm the exact connection.
What should I include in a wholesale 24V supply enquiry?
Include FY2400800, quantity, lighting load and input specification, connector drawing, polarity, cable lengths, mains-cord requirements, destination and packing. MOQ is 20 pcs and samples are available.
Which technical documents should I request for my market?
State the destination market and required documents in the enquiry. Request configuration-specific electrical and compliance information for the ordered model.
Compare the separately pictured 12V supply
Select the output voltage and connection from the lighting specification before requesting a sample.
